Plate mount / satellite mount 2.0 inch x 3 foot L section


Heavy duty welded and hot dip galvanised plate mount / satellite mount (do not confuse with seemingly similar products of pressed steel construction and inferior plated (or pre galvanised) finish)


2.0 inch x 3 foot L section plate mount / satellite mount

A heavy duty plate mount in hot dip galvanised steel, finish may vary, do not confuse with inferior pre galvanised / plated pressed steel types

The “pole” is 2.0 inch diameter by 2.0mm / 14 gauge wall thickness and the bottom plate (approx 10 in square, see dimensions on the product picture) is 5mm steel.

Recommended for any TV aerial or a satellite dish up to 1 metre.

Other plate mounts are available :
2in x 3ft straight plate mount
1.25in x 3ft L Section plate mount
Also see heavy duty flat roof mounting kit

Wall anchors (if required) are here :
Screws (50 & 75mm) with standard plugs / screws (50mm) with universal plugs / sleeve anchors

Keeper plates” to fit this plate mount are also available, useful when installing on metal or wooden skinned buildings.

Unfortunately a non conveyable carrier surcharge applies to this product.
